12.4m 3-axle flatbed semi trailer with FUWA 13T axle
  • 12.4m 3-axle flatbed semi trailer with FUWA 13T axle - 0 12.4m 3-axle flatbed semi trailer with FUWA 13T axle - 0
  • 12.4m 3-axle flatbed semi trailer with FUWA 13T axle - 1 12.4m 3-axle flatbed semi trailer with FUWA 13T axle - 1
  • 12.4m 3-axle flatbed semi trailer with FUWA 13T axle - 2 12.4m 3-axle flatbed semi trailer with FUWA 13T axle - 2
  • 12.4m 3-axle flatbed semi trailer with FUWA 13T axle - 3 12.4m 3-axle flatbed semi trailer with FUWA 13T axle - 3
  • 12.4m 3-axle flatbed semi trailer with FUWA 13T axle - 4 12.4m 3-axle flatbed semi trailer with FUWA 13T axle - 4
  • 12.4m 3-axle flatbed semi trailer with FUWA 13T axle - 5 12.4m 3-axle flatbed semi trailer with FUWA 13T axle - 5

12.4m 3-axle flatbed semi trailer with FUWA 13T axle

You can rest assured to buy customized 12.4m tri-axle flatbed semi trailer from us. We look forward to cooperating with you, if you want to know more, you can consult us now, we will reply to you in time! JUPITER® is a large-scale semi trailer and special vehicles manufacturer and supplier in China. We have been specialized in semi trailer and special vehicles for more than 38 years. Our 12.4m 3-axle flatbed semi trailer with FUWA 13T axle have a good price and quality advantage and had already exported to the Asia, Africa and South America countries. We look forward to becoming your long-term partner in China.

Send Inquiry

PDF DownLoad

Product Description

We're known as one of the most professional 12.4m 3-axle flatbed semi trailer with FUWA 13T axle manufacturers and suppliers in China. Our factory offers high quality products made in China with competitive price. Welcome to place an order.



This JUPITER® 12.4m 3-axle flatbed semi trailer with FUWA 13T axle is suitable for carrying ISO 20FT and 40FT containers, bulk cargo such as steel,stone which are mostly used in short and long distance transportation. 12.4m 3-axle flatbed semi trailer with Mechanical suspension is the best choice for the transportation and operation of bulk cargos,20ft and 40ft container van box with high efficiency and economic return, we use famous brand parts on 12.4m 3-axle flatbed semitrailer with Double Coin 12R22.5 Tire, such as FUWA or BPW Brands Axle, JOST King Pin.so we recommend the end users or drivers to choose this 12.4m 3-axle flatbed semi trailer with FUWA JOST 2 inch 3.5 inch king pin and welcome to inquiry about our 12.4m 3-axle flatbed semi trailer.

JUPITER 12.4M 3-AXLE FLATBED SEMI TRAILER Parameter (Specification)

Type

12.4m 3 Axles Flatbed Semi-Trailer

Model

FTW9402TP

Parameter

Dimension(mm)

length×width×height:12410×2500×1560mm

King Pin Setting(mm)

950

Fifth Wheel Height(mm)

The height will be adjusted according to the tractor specification

Axle Space(mm)

7500+1310+1310

Tare Weight（kg）

7,200

Payload（kg）

32,800

Fabric

Main Beam(mm)

500, submerged arc welding Q345B

Flange and Web(mm)

14/6/16

Flooring

3mm Checkered Plate

Lock

08 retractable locks

Paint

primer + top coat

OEM

Landing Gear

FUWA 19”

Kingpin

50＃，FUWA

Brake System

30/30 type onrear two axles with brake valve

ABS

No

Suspension

Mechanical suspension with8 leaf spring

Axle

FUWA L1 BPW 13T. Number: 3

Tire

Double Coin Brand 12R22.5-18PR, Number:12

Rim

9.0*22.5 Number:12

Tool box

1 set on right side, 1m, steel

Spare Tire Carrier

equipped 2 sets per chassis

Color

/

According to customer’s requirements

Others



● “LONG VEHICLE” sign on the rear end.

● LED lights，equip side turn light.

● Main beam: stick “JUPITER” logo

● Mud flap: stick “JUPITER ”

● Nameplate: English model
