20ft Sidelifer Side Loader Container Semi Trailer with Xcmg 37 Tons Crane

JUPITER is a large-scale semi trailer and special vehicles manufacturer and supplier in China. We have been specialized in semi trailer and special vehicles for more than 39 years. Our 20ft 3 axles sideloader trailer with Fuwa 13T axle have a good price and quality advantage and had already exported to the Asia, Africa and South America countries. We look forward to becoming your long-term partner in China.

Send Inquiry

Product Description

This JUPITER 20ft 3 axles sidelifter container trailer is suitable for carrying ISO 20FT containers, which are mostly used in the port, pier and container yards. 20ft 3 axles sideloader trailer with BPW Axle is the best choice for the transportation and operation of 20ft container van box with high efficiency and economic return, we use famous brand parts on 20ft 3 axles sidelifter container trailer with JOST 2 inch King Pin, such as FUWA or BPW Brands Axle, JOST King Pin.so we recommend the end users or drivers to choose this 20ft 3 axles sideloader trailer with 19 inch Landing Gear and welcome to inquiry about our 20ft 3 axles container trailer.

SELF LOADER CONTAINER TRAILER

DESCRIPTION ITEM UNIT
PARAMETERS
LIFTING PERFORMANCE MAX. LIFTING CAPACITY KG 37000
MAX. WORKING RANGE MM 4000
MAX. STABILIZER OUTREACH MM 3200
WEIGHT CURB MASS KG 8500
MASS OF SIDELIFTER KG 7250
MAXIMUM GROSS MASS KG 40000
DIMENSION OUTLINE DIMENSION OF SEMI-TRAILER(L×W×H) MM 9250×2500×4000
OUTLINE DIMENSION OF SIDELIFTER(L×W×H) MM 1020×2500×2490
WHEEL BASE MM 4000+1350+1350
TRACK(FRONT AXLE/REAR AXLE) MM 1820/1820/1820
FRONT OVERHANG / REAR OVERHANG MM -/2370
APPROACH ANGLE/DEPARTURE ANGLE ° -/13
ENGINE(OPTIONAL) MODEL ——  V2403-M-DI-E3B-CSL-1
KUBOTA V2403-M-DI-E3B-CSL-1
POWER/ROTATION SPEED KW/R/MIN 36.5/2600
EMISSION STANDARD ——
OFF-ROAD, EURO III

SELF LOADER CONTAINER OPTIONS


· FUWA, BPW or Certificated Quality  Axles

· Single or Double tyres

· EBS or ABS brake system

· Aluminum Rims or Steel Rims

· 2,3 or 4 Axles

· Mechanical or Air Suspension

· Side Lifter Semi Trailer, Side Loader Semi Trailer, Contaner Side Loader Semi Trailer Trailer, Self Loader Container Trailer
