35cbm 3 Axles Tipper Semi Trailer with Fuwa 13t Axle

JUPITER® is one of the most professional 35cbm 3 Axles Tipper Semi Trailer with Fuwa 13t Axle manufacturers and suppliers in China, featured by good service and competitive price. Please feel free to buy high quality 35cbm 3 Axles Tipper Semi Trailer with Fuwa 13t Axle made in China here from our factory.

This JUPITER® 35cbm 3 Axles Tipper Semi Trailer with Fuwa 13t Axle  is suitable for carrying Construction materials such as sands,stone which are mostly used in constructions industry and mining site.  Our heavy duty tipper trailer with Hyva cylinder is the best choice for the transportation and operation of construction materials, bulk cargo with high efficiency and economic return, we use famous brand parts on U shape dumper trailer with 12.00R20 tire, such as FUWA or BPW Brands Axle, JOST King Pin.so we recommend the end users or drivers to choose this mining use dumper semi trailer and welcome to inquiry about our 3 axles dumper semi trailer.

TECHNICAL HIGHLIGHTS

• FUWA,BPW or Certificated China Axles
• Hyva Brand Hydraulic Cylinder
• Hydraulic or Pneumatic Roof
• High Quality Steel usage
• Air or Mechanical or Hydraulic Suspension
• Dimensions As Per The Buyer Request

Type		35cbm 3 Axles Dumper Semi-Trailer
Model		JPT9402ZZX
Parameter	Dimension(mm)	length×width×height:10500×2500×3580mm
	King Pin Setting(mm)	958
	Fifth Wheel	The height will be adjusted according to the tractor specification
	Height(mm)
	Axle Space(mm)	4650+1310+1310
	Tare Weight（kg）	Approx. 9500
	Payload （kg）	60000
Fabric	Main Beam(mm)	500, submerged arc welding Q345B
	Flange and Web(mm)	14/16/8mm
	Paint	primer + top coat
OEM	Landing Gear	FUWA 19”
	Kingpin	50＃，FUWA
	Brake System	30/30 type on rear two axles, SEALCO brake valve
	Hydraulic System	CHengyitong Brand 214×5×6800×65
	Suspension	Mechanical suspension with 8 leaf spring
	Axle	Factory Standard 13T. Number: 3
	Tire	12.00R20-18PR, Number:12
	Rim	8.5*20 Number:12
	Tool box	1 set on right side, 1m, steel
	Spare Tire Carrier	equipped 01 set per chassis
Color	/	According to customer’s requirements
Others		● “LONG VEHICLE” sign on the rear end.
		● LED lights，equip side turn light.
		● Main beam: stick “JUPITER” logo
		● Mud flap: stick “JUPITER ”
		● Nameplate: English model

Note:
All the details not mentioned above should comply with Chinese regulations.
JUPITER does NOT take any responsibility on the trailer’s registration in the terminal country.
