40ft 2-axle flatbed semi trailer with FUWA 13T axle

You can rest assured to buy 40FT 2-AXLE FLATBED SEMI TRAILER from our factory and we will offer you the best after-sale service and timely delivery. JUPITER® is a large-scale semi trailer and special vehicles manufacturer and supplier in China. We have been specialized in semi trailer and special vehicles for more than 40 years. Our 40ft 2-axle flatbed semi trailer with FUWA 13T axle have a good price and quality advantage and had already exported to the Asia, Africa and South America countries. We look forward to becoming your long-term partner in China.

Send Inquiry

PDF DownLoad

Product Description

As one of the leading 40ft 2-axle flatbed semi trailer with FUWA 13T axle manufacturers and suppliers in China, we warmly welcome you to buy high quality 30ft 2-axle flatbed semi trailer with FUWA 13T axle made in China here from our factory. Good service and competitive price are available.


This JUPITER® 40ft 2-axle flatbed semi trailer with FUWA 13T axle is suitable for carrying ISO 20FT and 40FT containers, bulk cargo such as steel,stone which are mostly used in short and long distance transportation. 30ft 2-axle flatbed semi trailer with mechcnical suspension is the best choice for the transportation and operation of bulk cargos,20ft and 40ft container van box with high efficiency and economic return, we use famous brand parts on 40ft 2-axle flatbed semitrailer with 16T Axle, such as FUWA or BPW Brands Axle, JOST King Pin.so we recommend the end users or drivers to choose this 40ft 2-axle flatbed semi trailer with 3mm checkered plated and welcome to inquiry about our 30ft 2-axle flatbed semi trailer with 12R22.5 tire.

JUPITER 30FT 2-AXLE FLATBED SEMI TRAILER Parameter (Specification)

Type

40FT 2 Axles Flatbed Semi-Trailer

Model

JPT9405TP

Parameter

Dimension(mm)

length×width×height:12420×2500×1560mm

King Pin Setting(mm)

950

Fifth Wheel Height(mm)

The height will be adjusted according to the tractor specification

Axle Space(mm)

5500+1310

Tare Weight(kg)

6,100

Payload(kg)

33,900

Fabric

Main Beam(mm)

500, submerged arc welding Q345B

Flange and Web(mm)

14/6/16

Flooring

3mm Checkered Plate

Lock

08 retractable locks

Paint

primer + top coat

OEM

Landing Gear

FUWA 19”

Kingpin

50#,FUWA or JOST

Brake System

30/30 type onrear two axles with brake valve

ABS

No

Suspension

Mechanical suspension with 8 leaf spring

Axle

13T. Number: 2

Tire

12R22.5, Number:08

Rim

9.0*22.5 Number:08

Tool box

1 set on right side, 1m, steel

Spare Tire Carrier

equipped 2 sets per chassis

Color

 /

According to customer’s requirements

Others



● “LONG VEHICLE” sign on the rear end.

● LED lights,equip side turn light.

● Main beam: stick “JUPITER” logo

● Mud flap: stick “JUPITER ”

● Nameplate: English model


Hot Tags: 40ft 2-axle flatbed semi trailer with FUWA 13T axle, Manufacturers, Suppliers, Factory, China, Wholesale, Customized, Low Price, Made in China
