Flatbed Semi Trailer
JUPITER® is a large-scale semi trailer and special vehicles manufacturer and supplier in China. We have been specialized in 40ft 4 axles flatbed semi trailers with BPW 13T axle for more than 38 years. Our 40ft 3-axle flatbed semi trailer with FUWA 13T axle have a good price and quality advantage.
Flatbed Semi Trailer.
Send Inquiry
Product Description
Flatbed Semi Trailer
This Flatbed Semi Trailer is suitable for carrying ISO 20FT
containers, which are mostly used in the port, pier and container yards. 20ft 2 axles flat bed
semi trailers with FUWA Axle is the best choice for the transportation and
operation of 20ft container van box with high efficiency and economic return,
we use famous brand parts on 20ft 2
axles flat bed semi
trailers with JOST 2 inch King Pin, such as FUWA or BPW Brands Axle, JOST King
Pin.so we recommend the end users or drivers to choose this 20ft 2 axles flat bed semi trailers with Double
coin12R22.5 tires . We have flat bed semi trailer for sale, welcome to inquiry .
| Specification: |
|
|
| Type: | 20FT 2 Axles Flatbed Semi Traile | |
| Model | JPT9352TJZG | |
| Dimension: |
|
|
|
|
Length: | 7, 200mm |
|
|
Width: | 2, 480mm |
|
|
Height: | 1, 540mm |
|
|
Wheel Base: | 4150+1310mm |
| Frame & Structure: |
|
|
|
|
Main beam: | Material Q345B. Fabricated “H” beam height 500mm, Top flange thickness 12mm, Middle web thickness 6mm, Bottom flange thickness 14mm |
|
|
Side beam: | 14# channel steel |
|
|
Platform: | 2.5 mm thick diamond plate with supporting channel, 4 lines 40*30 shaped steel |
|
|
Kingpin: | 2’(50#), bolted in type |
|
|
Twist lock: | 04 sets twist locks |
|
|
Welding standard: | All welding are to be done by qualified welder per applicable national standard |
|
|
Painting: | Shot blast at Standard SA 2.5 prior to application of primer, polyurethane top coat. Total DFT not less than 100um |
| Running gear: |
|
|
|
|
Suspension: | mechanical suspension, heavy duty leaf spring 7 pcs-16mmx90mm, China |
|
|
Axle: | Fuwa brand 2 pcs*13 ton capacity, China |
|
|
Brake system: | Dual line pneumatic brake, SAE hose and connector, without ABS |
|
|
Brake chamber: | 2 units T30/30 spring brake chambers, 2 units T30 brake chambers |
|
|
Air tank: | 40L, 1pc, China |
|
|
Tire: | 12R22.5, 8 pcs. China |
|
|
Rim: | 9.0*22.5 steel disc wheel, 10 holes ISO, 8pcs. China |
|
|
Landing gear: | Fuwa 19 Inch two speed telescopic manual landing gear |
|
|
|
|
| Electrical System: |
|
|
|
|
Voltage: | 24 Volt |
|
|
Receptacle: | 7 way socket SAE standard, China |
|
|
Front marker lamp: | White |
|
|
Side marker lamp: | White & Red |
|
|
Rear lamp: | Red |
|
|
Turn signal lamp: | Amber |
|
|
Reflector: | Per customer requirement |
|
|
Wiring: | Electric cable protected by PVC conduit on main frame |
|
|
|
|
| Accessories: |
|
|
|
|
Mud guard: | Steel mud guard |
|
|
Spare wheel carriers: | 1 pc |
|
|
Tool box: | 1 pc |
| Note: All the details not mentioned above should comply with Chinese regulations. If any component or structure changed, the price shall be modified accordingly. | ||
